# Nornir-Maze
```diff
! Documentation under construction ...
```
### Introduction
Nornir_maze is a collection of Nornir tasks and general functions in Nornir stdout style.
By now nornir_maze contains the following modules:
#### General Modules with Helper Functions
* nornir_maze.git
* nornir_maze.utils
#### Cisco Software Upgrade
* nornir_maze.software_upgrade.utils
* nornir_maze.software_upgrade.nr_software_upgrade (ready-to-use script)
#### Cisco Support API
* nornir_maze.cisco_support.utils
* nornir_maze.cisco_support.api_calls
* nornir_maze.cisco_support.reports
#### Cisco Configuration Management
* nornir_maze.configuration_management.utils
* nornir_maze.configuration_management.pyats
* nornir_maze.configuration_management.cli.show_tasks
* nornir_maze.configuration_management.cli.config_tasks
* nornir_maze.configuration_management.cli.config_workflow
* nornir_maze.configuration_management.restconf.tasks
* nornir_maze.configuration_management.restconf.cisco_rpc
* nornir_maze.configuration_management.restconf.config_workflow
* nornir_maze.configuration_management.netconf.ops_tasks
* nornir_maze.configuration_management.netconf.config_tasks
* nornir_maze.configuration_management.netconf.config_workflow
## Installation
In order to use the tasks and functions from nornir-maze you will need to install the library from Pypi.
```bash
pip install nornir-maze
```
## Scripts Ready-to-Use
### nr_software_upgrade.py
The module `nornir_maze.software_upgrade.nr_software_upgrade` of nornir-maze is a ready-to-use script which can be imported and executed as shown below. The nr_software_upgrade script should work for the whole Cisco Catalys 9000 series. There are two options available to copy the software to the switches, which are an upload with SCP or a download with HTTP. Every task that is possible is first executed with RESTCONF and in case RESTCONF fails for any reason, then a CLI fallback task will be started only for the failed hosts.
```python3
#!/usr/bin/env python3
"""
OWN DESCRIPTION
"""
from nornir_maze.software_upgrade import nr_software_upgrade
def main() -> None:
"""
This is the main function and is executed when the file is directly executed.
"""
nr_software_upgrade.main()
if __name__ == "__main__":
main()
```
The script needs from the Nornir inventory a dictionary called `software` with three key value pairs. The `version` specifies the desired version which will be verified in the beginning in order to only taget host which really needs a software upgrade. The `filepath` specifies the path and filename and is needed of the SCP upload argument `local_upload` is used. The `http_url` is used as the default method if the `local_upload` argument is not used. Only one of both key value pairs are mandatory depending which method is used. Please read the comment below regading the dependencie of the `filepath` and the `http_url` key value pair.
To structure the Nornir inventory for different versions or files the `software` dictionary can be used in groups for the specific device us usecase.
```yaml
#### Cisco IOS-XE Software ###################################################################################
# The key "filepath" is mandatory for SCP upload and the key "http_url" is mandatory for HTTP download. If
# both keys "http_url" and "filepath" are present, then the md5 hash verification is made with "filepath"
# rather then with "http_url". This is much faster as the md5 hash can be computed directly on the local disk.
iosxe_c9200:
data:
software:
version: 17.03.04
filepath: docker_srv_httpd_nr_cm/htdocs/cat9k_lite_iosxe.17.03.04.SPA.bin
http_url: http://10.1.10.180:9999/cat9k_lite_iosxe.17.03.04.SPA.bin
iosxe_c9300_c9600:
data:
software:
version: 17.03.04
filepath: docker_srv_httpd_nr_cm/htdocs/cat9k_iosxe.17.03.04.SPA.bin
http_url: http://10.1.10.180:9999/cat9k_iosxe.17.03.04.SPA.bin
```
